W11 Led Neon Flex – CE RoHS 3years
Short Description:
| *Great for architectural lighting solution, outdoor decorative lighting solution |
| *Ideal Placement For Traditional NEON Light, Offer Generous And Rich Colors |
| *No Dark Spot And Consistent Color Throughout The Whole Rope Light |
| *Power Connector, Mounting Track, Mounting Clip, End Cap.for DIY project |
| *DC 24V/12V Anti-Electric Shock, safty for outdoor usage |
| *UV and Yellowish Resistant,IP67 waterproof and Salt-mist proof |
try it now!
Product Detail
Product Tags
| The LED NEON FLEX is a versatile and user-friendly lighting device; it can be cut and bent and formed in the field and easily installed on the flat surface of varied materials, such as wood, plastic, steel, or wall, etc. to form all kinds of pattern according to your design. And it can be easily connected to the power supply and then performs well. | |
| -It is recommended to mark centerlines or draw the outline of your pattern on the surface of your desired positions. | |
| -Secure mounting clips on the centerlines at appropriate intervals with screws, if there are curves; It is better to secure mounting clip on each curve and between. | |
| -Insert the light body into the mounting clips with the lighting parts upward. | |
| -Connect each part together. | |
| Parameters: | |
| LED Light Source | SMD2835 |
| Light Type | LED Neon Light |
| Input Voltage(V) | DC12V/24V |
| Lamp Power | 12W/M |
| Lamp Luminous Flux(lm) | 690lm/mtr |
| CRI | Ra>70 |
| Color | White(3000K/4000K/6000K),Red,Green,Blue,Yellow |
| Working Temperature(℃) | -20~50℃ |
| Working Lifetime(Hour) | 50000Hrs |
| Lamp Body Material | PC |
| Certification | CE, EMC,LVD, RoHS |
| Place of Origin | Shenzhen,China |
| Brand Name | MSS LED or OEM |
| Model Number | NF1120A |
| Product Name | Flex LED Neon Light |
| LED Quantity | 120LED/M |
| PCB Color | White PCB |
| IP Rating | IP67 |
| Dimension | W11*H20mm |
| Drawing |  |
| Warranty | 3years |
| Min cut | 10cm |
| Beam Angle | 120 degree |
| Length | 10Meters/roll |
| Application: | |
| LED neon letter or sign | |
| Building and sign outline lighting | |
| General and cove lighting | |
| Ships, boats and trucks outline lighting | |
| Bathroom, spa room lighting | |
| Applicable for automobile and bicycle decoration, border or contour lighting | |
Why you choose Neon Flex from MSS LED:
How to install neon flex:
(below neon color only for reference, pls make the object as the standard)
What accessories you need for neon flex:
How you connect neon flex and cables:
